Orbit PowerJack 7014 for Futaba R7014SB Receivers by Evojet 2714

The Orbit PowerJack 7014 is a 14 channel Servobox with double voltage regulators for all 7014 receivers. It will be plugged directly by tight precision contacts onto the 7014. The power will be supplied via two MPX high amp connectors from the battery(ies) or the switch harness(es). Because of its small and lightweight construction, the Power-Jack 7014 is particular suited for middle and large models with long wiring and digital servos.

Servobox: 14 ch 5 V impulse out
Power Supply: single or double battery 4.8V – 8.5 V HV for the servos
Rating: up to 30 Amps
Connections: JR / Uni / Futaba with Goldpins
Dimensions: 57 x 28 x 16 mm
Weight: 20 g
Package includes: PowerJack 6014 and two MPX connectors (suitable power switch harness see Item: [2714])

Instructions PDF
